Serial Number 45 (Total quantity 477) One of small group bearing 1881 inspectors' mark A superior early production example; subsequently became the US Model 1875 Very fine plus - SOLD. This is an excellent example of a Type I Officer's Trapdoor Rifle that was manufactured by Springfield Armory between 1874 and 1881. Trapdoor Production Data for Models 1873, 1875, 1877, 1884 and 1888 Calendar Year Rifles Carbines Cadet Rifles Ramrod Bayonet Rifles Officer's Model 1875 Forager Shotgun ONLY New Arms Produced Observed Final Ser.No. 1873 5 1,942 0 0 0 0 1,947? 1874 22,397 10,873 1 0 0 0 35,218? 1875 17,393 7,211 499 0 10 0 60,321? 1876 11,369 2 2,517 0 115 0.

(Redirected from Springfield Model 1884)
1873
Springfield model 1884
TypeBreech-loading rifle
Place of originUnited States
Service history
Used byUnited States Army
WarsIndian Wars, Spanish–American War, Philippine–American War
Production history
Designed1884
ManufacturerSpringfield Armory
Specifications
Length51.875 in (1,317.6 mm)
Barrel length32.625 in (828.7 mm)
Cartridge.45-70-500
ActionHinged breechblock
Rate of fireApprox. 10 rounds a minute
Muzzle velocity1,315 feet per second (401 m/s)
TrapdoorNumbers

The Springfield model 1884 was one of the 'Trapdoor Springfield' rifles. It was an improved replacement for the previous longarm of the U.S. Armed Forces, the Springfield model 1873.

Description[edit]

The model 1884 traces its roots back to the design of the Springfield 1873. The model 1884 incorporated a significant number of improvements that had been made between 1878 and 1879. It also featured a serrated trigger that had been incorporated into the Springfield rifle design in 1883.

1873 Trapdoor Serial Numbers
The Buffington rear sight raised on a model 1884
Springfield model 1873 trapdoor serial numbers
Model 1884 lock work

The most dramatic change to the rifle design, which is often considered to be the identifying feature of the model 1884, was a new rear sight which had been designed by Lieutenant Colonel Adelbert R. Buffington of the U.S. Army Ordnance Department. This sight however was not perfected until 1885.

The principal feature of this new sight was a rack and pinion style windage adjustment. Unlike previous sights, the base was not used for any position other than point blank. The raised leaf had graduations from 200 to 1400 yards. A new barrel band was also designed to accommodate this new sight so that it could lie flat in the point blank position.[1]

Marksmen generally favored the new sight, but general troops were less enthusiastic about it and often considered it to be an annoyance.

The model 1884 was also produced in a carbine version. It was found that the rear sight could be easily damaged when removing the rifle from the carbine boot. The rear barrel band was therefore modified in 1890 to include a rear sight protector.

A round-rod bayonet model was also produced, designated the Model 1888. This, like the Springfield model 1880, was an attempt to combine the cleaning rod and bayonet into a single unit. The Model 1888 included an improved retaining mechanism, as the Model 1880's retaining mechanism had proved to be problematic.
