Cam And Crank Sensor Simulator

Cam and crank sensor

Electromotive offers a selection of custom magnetic and Hall effect crank and cam sensors for use with our systems.

Crank Sensor Replacement

Cam And Crank Sensor SimulatorCam crank sensor symptoms
  • 1/2″ Magnetic Crank Sensor

    1/2” magnetic crank sensor for use with all Electromotive systems. Can be used with trigger wheels 3” or larger. Should not be used as a cam trigger.

  • 3/8″ Chisel Point Magnetic Sensor

    3/8″ chisel point magnetic sensor for use with all Electromotive systems. The 3/8″ chisel point sensor features a fine chisel point exposed sensor element for use with small-diameter, fine-pitch trigger wheels. It should be used with 60-2 trigger wheels under 3″ and all camshaft speed wheels. It can also be used to replace early flat […]

  • 1/2″ Hall Effect Crank Sensor

    1/2″ diameter smooth bore Hall effect crank sensor. This sensor is directly interchangeable with the standard 1/2″ magnetic crank sensor. This sensor can be used on any Hall effect-compatible Electromotive systems and will work on trigger wheels 3″ or larger. Hall effect crank sensors can often be used to address noise related starting/running issues, as […]

  • Hall Effect Cam Trigger w/ Pull-Up Resistor

    Threaded body Hall effect cam sensor. For use with custom cam trigger setups; includes pre-installed pull-up resistor.

  • Universal Cam Trigger Kit

    Universal cam trigger kit allows the addition of a cam reference on engines not equipped with one. A cam reference is necessary if sequential injection firing is desired. The kit includes 2.5″ mild steel cam trigger wheel with 10mm I.D. and threaded body Hall effect cam sensor.

  • Crank Trigger Simulator

    The Crank Trigger Simulator creates a variable RPM Signal in a 60-2 pattern. Allows for running Electromotive TEC and XDi systems without the engine running. This is beneficial for calibrating the XDi’s manual potentiometers, as well as general system testing on any unit. Also provides a cam pulse for testing sequential injection functionality on TEC […]

  • Y Cable Assembly

    Y cable assembly allows for a single-crank sensor’s signal to be split to two systems. This is commonly used on legacy systems such as the HPV and HPX when used in a dual-plug configuration. It is used in conjunction with the 3/8″ or 1/2″ sensors to replace early Y cable sensors.

  • GM 2-Wire Crank Sensor Adapter

    Cable for adapting 3-position Weather Pack crank sensor plug to the 2-wire GM Ecotec block-mounted crank sensor. For use only with GM engines running 58-tooth trigger wheels. *Note: GM engines do not use the 11th tooth for TDC reference. Always verify tooth location at TDC and compensate in your timing tables/knobs.

Cam

Crank Simulator Online

  1. Codes between P0335 and P0338 correspond to crankshaft sensor problems. This is probably the most straightforward and the most certain way to test for and identify a crankshaft sensor problem. Unfortunately, the crankshaft sensor is usually pretty worn by the time that the check engine light is on.
  2. The Electrothrottle and the Blue Voltage Reference Simulator is an unbeatable automotive diagnostic pair, providing E.C.M. Level regulated sensor voltage and and actuation. NEW-DEVELOPMENT: The Blue-Voltage now has a CAM-CRANK-WHEEL SPEED Sensor Output. It can be used to inject any speed sensor to the ECM.

Cam And Crank Sensor Simulators

Cam and crank sensors can be variable reluctance or Hall effect so analog or digital depending on the OEM. A 60 - 2 configuration means that there is a tone ring on the crankshaft that has spacing for 60 teeth, but only 58 are present. The two missing teeth identify the #1 cylinder at TDC.
